What is Docker?

Its a box of delights

25 December 2021 by Kevin McAleer


Docker Overview

Docker is an open-source platform for creating and managing software containers.


Containers

So what is a container? Here is a definition from the creators of docker:

“A container is a standard unit of software that packages up code and all its dependencies so the application runs quickly and reliably from one computing environment to another. A Docker container image is a lightweight, standalone, executable package of software that includes everything needed to run an application: code, runtime, system tools, system libraries and settings.” - Docker.com

Containers are much smaller than virtual machines, which is the alternative method for separating software services.

Containers are made up of several parts:

Component Description
Image Contains the software to be run
Volume The data storage, can be stored as a separate file, or mounted from the local file system
Port Network ports that the container exposes to the local network, can allow mapping between internal port and external ports
Network Networks can be used to connect images together - its a bit like having a virtual network switch

We will look at each of these components below. To jump to a section click on Containers Images, Volumes Networks

Why not just install software?

Docker turns software into blocks of software, called images, that can be switched on and off very easily, it also ensure that dependent libraries and configuration are all inside the container. This makes it really easy to install software, start it up, run it and when the time comes, stop it and remove it.

Docker also has a restart policy which restarts the software automatically if the containers fails.

Docker Image Repository - Docker hub

Docker has an official repository of software images, called Docker Hub. You can browse or search the hub for officially tested images, and you can download up to 100 images for free, every 6 hours.

Installing containers

Installing software containers could not be easier. For example, to install Nginx (a popular web server) the command is:

docker run -itd nginx

…and thats it!

List all the running containers

To list all the currently running containers, simply type:

docker ps

To show all the containers, including stopped containers, type:

docker ps -a

Starting a container

If a container is stopped, you can restart it by typing:

docker start <container-name>

Where container-name is the name of the container you want to start.

Stopping containers

To stop a container, simply type:

docker stop <container-name>

Where <container-name> is the name of the container you want to stop.

Removing containers

To remove a container, type:

docker rm <container-name>

Where <container-name> is the name of the container you want to remove.

Container options

You can configure container options, such as the restart policy, by using the update command. For example, to set the restart policy to always restart on the Portainer container type:

docker update --restart=always Portainer

To give your containers a specific name, you can use the --name option, when creating it; for example to use the image getting-started and name the container as Welcome type:

docker run getting-started --name=Welcome

Images

An image is a pre-configured bundle of software, frozen into a package that can be easily copied and run in a docker environment.

Creating Images - Build

To create your own image, use the docker build command. Docker will look for a Dockerfile in the current directory and use that to construct the new image.

docker build

Listing the images

To list all the images that are currently installed (but not necessarily running as containers), type:

docker images ls

Where <image-name> is the name of the image you want to pull.

To pull an image

If you want to cache an image ready for use, but not actually start a container, simply type:

docker image pull <image-name>

Removing images

To remove an image type:

docker image rm <image-name>

Where <image-name> is the name of the image you want to remove.


Volumes

A volume is a data file or mount point to the local file system that can be used to store data for the container.

By separating volumes from images we separate the executable code from the storage of data. This means we can quickly upgrade the software without affecting the underlying data. Or if we want to move the data to another server, its just a matter of copying the volume file.

Creating Volumes

Volumes can be quickly created by typing:

docker volume <volume-name>

Where volume-name is the name of the volume to create.

Listing Volumes

To list all the volumes available, type:

docker volume ls

Removing Volumes

To remove a volume type:

docker volume rm <volume-name>

Where volume-name is the name of the volume to remove.

Networks

Networks enable containers to talk to each other, without exposing that network traffic outside of the host. The can also enable containers to talk to other computers outside of the host.

Listing networks

To list all the available networks, type:

docker network ls

Creating network

To create a new network, type:

docker network create <network-name>

Where network-name is the name of the new network you want to create.

Removing networks

To remove a network, type:

docker network rm <network-name>

Where network-name is the name of the new network you want to remove.


Ports

Ports enable data to flow in and out of your container on a specific unix port number.

Opening a port on a container

When creating a container, you can use the -p option to specify the port to expose from the container to the host. For example to expose the container port 80 to the host port 80, type the following:

docker run -p 80:80 <container-name>

Where container-name is the name of the container and the 80:80 is the mapping is from the host to the container (host:container). For example, to map port the host port 80 to the container port 8080 you would type -p 80:8080


Creating Containers in code

Using the command-line is great for quickly creating, running and managing docker containers, however if you want to create containers more programmatically you can use a Dockerfile.

Dockerfile

A dockerfile tells docker how to build the image we want to create.

Here is an example dockerfile:

FROM alpine:latest AS getfiles
# install git
RUN apk --no-cache add git
RUN mkdir /src
WORKDIR /src
RUN git clone https://www.github.com/kevinmcaleer/ClusteredPi

In the example above, we specify which image to build the container FROM, which is the latest version of alpine linux, we then RUN the command apk --no-cache add git to add the git package, using the apk package manager.

We then RUN another command to create the folder /src.

Next we set the working directory to /src using the WORKDIR keyword.

Finally we RUN the command line git clone and the name of the git repository we want to copy.

The result is a linux image with our source code installed.

Docker-compose

A Docker-compose file, usually called docker-compose.yml.

A Docker-compose file contains all the configuration that you would normally specify at the command-line but in a file.

Here is an example docker-compose.yml file:

version: "3.9"
services:
  myapp:
    environment:
      JEKYLL_UID: 1000
      JEKYLL_GID: 1000
      JEKYLL_ENV: production
    build: .
    ports:
      - "2222:2222"
    # image: myapp
    restart: always

First we specify the version of docker-compose we are using, which in this case is 3.9. We then define the services, which in this case is just one container called myapp.

myapp has three environment variables. We then use the build command with the parameter . which tells if to build the image from the current folder.

We then expose the ports 2222:2222 from the host to the container.

Next is a comment #, which docker-compose ignores. Finally we set the restart policy to always restart. This will ensure that docker always starts this container up at boot/start-up too.

Prune all unused images and containers

To clean up your system, and remove any unused images or containers, type:

docker system prune
